Filter cloth is the working interface between the slurry and a vacuum disc filter. A cloth that is too open may pass fine solids into the filtrate. A cloth that is too tight may restrict liquid and air flow, blind rapidly, reduce capacity, and make cake discharge unreliable. The correct choice balances particle retention, permeability, cake release, chemical resistance, mechanical strength, cleanability, and service life.
Cloth selection should therefore be based on filtration tests with representative slurry rather than on micron rating alone. Mineralogy, particle-size distribution, solids concentration, temperature, pH, reagents, required filtrate clarity, and the way the cake releases all influence the result.
Quick answer
The best vacuum disc filter cloth is the most permeable medium that still achieves acceptable solids retention and forms a stable, releasable cake. Select it by testing several candidate fabrics with the actual slurry, then compare specific filtration capacity, cake moisture, filtrate solids, cake discharge, blinding rate, washing response, and expected life. Do not choose cloth from nominal pore size alone.
During the submerged portion of the cycle, vacuum draws liquid through the cloth while particles bridge across its openings and build a cake. The cake then becomes part of the filtration medium. As the sector leaves the trough, air continues through the cake to remove moisture. At discharge, blow-back and cloth flexing help release the cake.
The cloth must support all four stages:
A medium that performs well in only one stage may still reduce total filter performance.
Before comparing fabrics, define the duty with data from the real process:
A sample taken only from settled material or clear supernatant can produce a misleading cloth recommendation. Keep the sample mixed and reproduce the expected feed condition during testing.
Air permeability describes how easily air passes through a clean fabric under a specified test condition. It is useful for comparing media, but it does not directly predict slurry filtration. Once particles bridge the openings, the resistance of the cake can dominate the cycle.
A highly permeable cloth may deliver fast initial flow but unacceptable solids loss. A low-permeability cloth may produce clear filtrate but limit throughput and blind quickly. The useful value is the operating window in which the cloth supports both acceptable clarity and capacity.
Monofilament yarns have smooth surfaces and defined openings. They often clean and release cake well. Multifilament or spun yarns can retain fine particles but may trap solids within the fabric and become harder to wash. Mixed constructions can balance retention and release.
Fabric finish also matters. Heat setting improves dimensional stability. Calendering can smooth the surface and alter permeability, which may improve cake release. Reinforced seams and correctly shaped bags protect high-stress areas around sector edges and fastenings.
The correct construction depends on the slurry; the same nominal opening can behave differently when weave, yarn, finish, and fabric thickness change.
Common media include polypropylene, polyester, and polyamide, but chemical compatibility depends on the complete liquid chemistry and temperature. Review:
Compatibility charts are a screening tool, not a substitute for supplier confirmation under the actual service conditions.
A cloth may retain fine solids yet fail commercially because the cake remains attached. Poor release creates carryback into the trough, uneven cake on the next cycle, dirty sectors, and higher wash-water use.
During trials, observe whether the cake:
The best result normally uses the lowest effective blow-back that provides dependable release without damaging the bag or disturbing adjacent filtrate zones.
Blinding occurs when particles, scale, precipitates, oil, or reagent residues restrict the fabric. Warning signs include falling filtrate flow, rising vacuum demand, uneven cake, higher residual moisture, and increased wash frequency.
Common contributors are:
Inspect removed cloth under magnification where practical. The location and type of deposit help distinguish poor media selection from a washing or chemistry problem.
Compare candidate media under the same feed and cycle conditions. Record:
Short tests identify poor candidates, but longer trials are needed to compare blinding and life. A fabric that starts strongly and declines rapidly may cost more than a slightly slower cloth that stays stable.
Good media cannot compensate for poor installation. Confirm that bags match the sector geometry, seams face the correct direction, clamps are secure, and fabric tension is uniform. Remove sharp burrs and inspect sector drainage surfaces before fitting new bags.
After installation, check each sector for leakage and observe the first operating cycles. A single loose seam or torn bag can contaminate combined filtrate and make the entire cloth selection appear unsuccessful.
Cloth cost includes more than the price of a replacement set. Compare:
A higher-priced cloth can be economical if it maintains capacity, releases cake reliably, and reduces change frequency.
Tongzhiren Filtration can evaluate slurry data, filtration targets, sector configuration, washing requirements, and candidate media as one duty. Send a representative slurry sample, particle-size distribution, feed chemistry, required capacity, cake-moisture target, and filtrate-quality requirement for review.
| Info@tzrfiltration.com | |
| +86 139 1246 6955 |
Should vacuum disc filter cloth be selected by micron rating?
No. Nominal opening or micron rating does not describe cake formation, permeability, blinding, release, chemistry resistance, or life. Test complete fabric constructions with representative slurry.
Does tighter cloth always produce clearer filtrate?
It may improve initial retention, but a stable cake often provides much of the final solids capture. Excessively tight cloth can reduce throughput and blind quickly without delivering a useful overall benefit.
When should filter cloth be replaced?
Replace it when damage, permanent blinding, loss of dimensional stability, poor cake release, or unacceptable filtrate solids cannot be corrected safely by cleaning or installation adjustment.
Why does new cloth sometimes produce cloudy filtrate?
Before a stable particle bridge forms, fine solids can pass through clean fabric openings. If cloudiness continues, investigate media suitability, feed condition, seams, bags, sector seals, and valve routing.
